Dual-radio access point as per Wi-Fi 6 (IEEE 802.11ax) for up to 3,550 Mbps, parallel operation at 2.4 GHz & 5 GHz, 4x4 MU-MIMO, OFDMA, USB, BLE, 1x 2.5GE, 1x GE, IEEE 802.3at PoE, WPA3, IEEE 802.1X, Multi-SSID, VLAN, 4 ext. ant., incl. PSU
Features
-
2.4 GHzYes
-
5 GHzYes
-
6 GHzNo
-
Band steeringYes
-
Channel bandwidth160
-
Ethernet LAN data rates10/100/1000/2500
-
Fast roamingYes
-
Maximal-Ratio Combining (MRC)Yes
-
Maximum data transfer rate3550
-
Maximum data transfer rate (2.4 GHz)1150
-
Maximum data transfer rate (5 GHz)2400
-
MIMOYes
-
MIMO typeMulti User MIMO
-
Modulation1024-QAM/256-QAM
-
Networking standardsIEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11d/IEEE 802.11g/IEEE 802.11h/IEEE 802.11i/IEEE 802.11n/IEEE 802.11v/IEEE 802.1x/IEEE 802.3at/IEEE 802.3az
-
Number of users511
-
Number of VLAN IDs4096
-
Quality of Service (QoS) supportYes
-
Spread spectrum methodOFDMA
-
VLAN supportYes
Packaging content
-
AC adapter includedYes
-
Cables includedLAN (RJ-45)
-
Number of products included1
-
Quantity per pack1
-
Quick start guideYes
Power
-
AC input voltage12
-
Power over Ethernet (PoE)Yes
Antenna
-
Antenna direction typeOmni-directional
-
Antennas quantity4
-
Antenna typeExternal
Vendor information
-
Brand NameLancom Systems
-
Homepagehttps://www.lancom-systems.com/products/wireless-lan/indoor-access-points/lancom-lx-6402
-
Warranty1
Design
-
Cable length3
-
Cable lock slotYes
-
Certification893 V2.1.1/CE : EN 62368-1:2014+AC:2015+A11:2017, EN 62479:2010, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 300 328 V2.2.2, EN 301/FCC Part 15B, 15C, 15E
-
Housing materialSynthetics
-
LED indicatorsYes
-
PlacementTable
-
Product colourWhite
Logistics data
-
Customs product code (TARIC)85176200
Ports & interfaces
-
DC-in jackYes
-
Ethernet LAN (RJ-45) ports2
-
USB 2.0 ports quantity1
-
USB connector typeUSB Type-A
Management features
-
Firmware upgradeableYes
Operational conditions
-
Operating relative humidity (H-H)0 - 90
-
Operating temperature (T-T)0 - 40
Security
-
Security algorithmsAES-CCMP/AES-GCMP/EAP-FAST/EAP-GTC/EAP-PEAP/EAP-TLS/EAP-TTLS/TKIP/WEP/WPA2/WPA3
