Product out of stock
Found similar product in stock: Q1656 (MPN: 02164-001)
EAN
7331021073944
In stock: 1-4
Delivery: 2-4 тижні
1/1.8” sensor, 4 MP, Day/night fixed box camera with Deep Learning Processing Unit (DLPU). Support for Forensic WDR and Lightfinder 2.0. Includes an IR corrected varifocal 3.9-10 mm F1.5 i-CS lens with remote zoom and focus. Multiple, individually configurable streams, H.264/H.265 with Zipstream and Motion JPEG. 4MP stream up to 60 fps, 30 fps with WDR. AXIS Object Analytics, Video motion detection, shock detection and active tampering alarm. AXIS Edge Vault with FIPS certified TPM for added cyber security. Barrel distortion correction, defogging, electronic image stabilization and scene profiles. MQTT Support. Two-way audio, audio detection with either built-in microphone or optional analog or digital microphone. Supervised I/O for alarm/event handling, MicroSD/MicroSDHC memory card slot for optional local video storage. Serial port for RS422/485 communication. Powered by IEEE 802.3af Type1 Class 3 (PoE) or 10-28 V DC power with redundancy. Includes black stand for wall and ceiling. Midspan or power supply not included.
Security
-
Alert notification typeE-mail
-
HTTPS encryptionYes
-
IP address filteringYes
-
MirrorYes
-
Password protectionYes
-
Security algorithmsEAP-TLS/FIPS 140-2/HTTPS
-
Video motion detectionYes
Audio
-
Audio detectionYes
-
Audio formats supportedADPCM/LC-AAC/LPCM/PCM
-
Audio system2-way
-
Audio system full duplexYes
-
Built-in microphoneYes
-
Voice codecsG.711/G.726/OPUS
Lens system
-
Auto focusYes
-
Closest focusing distance0.5
-
Focal length range3.9 - 10
-
Maximum aperture number1.5
-
Number of lenses1
-
Optical zoom2.5
-
Zoom capabilityYes
Management features
-
Behavior analysisLine crossing detection
-
Remotely operatedYes
Vendor information
-
Brand NameAxis
-
Warranty1
Storage
-
Built-in HDDNo
-
Card reader integratedYes
-
Compatible memory cardsMicroSD (TransFlash)/MicroSDHC/MicroSDXC
-
Flash memory8194
-
Internal memory2048
Camera
-
Camera shutter speed1/47500 - 1
-
Lens viewing angle, horizontal120
-
Lens viewing angle, vertical63
-
Minimum illumination0.01
-
Viewing angle, horizontal120
-
Viewing angle, vertical63
Performance
-
Connectivity technologyWired
-
Day/night modeYes
-
Dynamic range120
-
Infrared (IR) cut-off filterYes
-
Languages supportEnglish/French/German/Italian/Japanese/Korean/Polish/Portuguese/Russian/Simplified Chinese/Spanish/Traditional Chinese
-
Number of languages12
-
Placement supportedIndoor
-
PTZ modesDigital PTZ
-
Remote viewingYes
-
TypeIP security camera
-
Wide Dynamic Range (WDR)Yes
Power
-
DC output voltage10/28
-
Power consumption (max)7.7
-
Power consumption (Power over Ethernet (PoE))5.1
-
Power consumption (typical)4.6
-
Power source typeDC/PoE
Technical details
-
Doesn't containBFR/PVC
Network
-
Ethernet interface typeGigabit Ethernet
-
Ethernet LANYes
-
Live viewYes
-
Networking standardsIEEE 802.3/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3at/IEEE 802.3u
-
Quality of Service (QoS) supportYes
-
SIM card slotNo
-
Wi-FiNo
Ports & interfaces
-
Ethernet LAN (RJ-45) ports1
-
Headphone outputs1
-
Microphone inYes
-
RS-422 ports2
-
RS-485 ports2
Design
-
Fog proofYes
-
Form factorDome
-
Housing materialAluminium
-
Mounting typeCeiling/wall
-
Product colourBlack
Video
-
Gain control typeAuto
-
Image stabilizerYes
-
Maximum resolution2688 x 1512
-
Noise reductionYes
-
Privacy maskingYes
-
Supported graphics resolutions160 x 90/2688 x 1512
-
Text caption overlayYes
-
Total megapixels4
-
Video formats supportedH.264/H.265/M-JPEG
-
Video intelligence analyticYes
-
Video streamingYes
Packaging content
-
Number of cameras1
Image sensor
-
Number of sensors1
-
Optical sensor size1/1.8
-
Progressive scanYes
-
Sensor typeCMOS
Operational conditions
-
Operating relative humidity (H-H)10 - 85
-
Operating temperature (T-T)-20 - 60
-
Storage relative humidity (H-H)5 - 95
-
Storage temperature (T-T)-40 - 65
System requirements
-
Windows operating systems supportedYes
